What to Monitor

Chapter hero titled "Execution: Build it, run it, fix it at 3 AM." Cluster topology on the left showing a multi-leaf, multi-spine AI fabric with compute, network, and storage rendered in a blue and green palette. On the right, a system metrics log feed panel scrolling through real production events. Subtitle: the transition from theory to production. Mastering the 15-layer HPC stack and the production provisioning patterns that work at scale. Operations [Phase 6]: inference networking, production operations, comprehensive cluster build guides, bills of materials, and deep-dive incident RCAs.

Build it, run it, fix it at 3 AM. This chapter is where everything you learned in Phases 1–5 meets reality.

Standard DC monitoring (link up/down, BGP sessions, interface utilization) is necessary but not sufficient for an AI fabric. The signals that tell you a training job is in trouble are different — and often invisible to traditional NMS tools.

This page is the inventory. The next pages cover what each signal means when it goes bad.

Five golden signals dashboard mock. Panel 1 AllReduce step time (198 ms, healthy target ~200 ms). Panel 2 PFC pause count (2,143 per min, spiking upward — investigate, PFC storm forming). Panel 3 ECN mark rate (3.2 percent, edge of normal — creeping up). Panel 4 NIC error counters (zero — flat, clean optics). Panel 5 ECMP load balance per spine-leaf link (bar chart with seven balanced bars and one tall outlier at 2× the others — hash polarization).
All five on one dashboard. AllReduce step time is the customer's view; the other four diagnose where it went wrong.
After this page, you'll be able to
  1. Name the five golden signals — AllReduce step time, PFC pauses, ECN marks, RDMA NIC errors, and ECMP imbalance, and what good vs. bad looks like for each.
  2. Build the three dashboards — fabric health, job health, and NIC health, and know which counters belong on each.
  3. Read RDMA NIC counters — ethtool -S for rx_prio3_pause, out_of_buffer_discards, out_of_sequence, and np_cnp_sent / rp_cnp_handled, and what each one going up means.
  4. Stand up the telemetry pipeline — gNMI/sFlow off the switch, Prometheus off the NIC and NCCL plugin, into Grafana and Alertmanager, with alerts on anomalies not absolutes.

The five golden signals​

Borrowing from SRE conventions, the five signals you should have a dashboard for at all times:

1. AllReduce time per training step​

This is the customer-facing metric. If AllReduce time goes up, training slows down, real money is being burned.

  • Source: training application telemetry (NCCL provides per-step timings; PyTorch / Megatron / Jax log them)
  • What good looks like: stable, low variance step-to-step
  • What bad looks like: spikes, drift upward over time, large p99/p50 ratio

The network engineer can't see this directly without the training team plumbing it in. Make sure they do.

2. PFC pause frames per port​

Per-priority pause counters. Counts go up when a buffer fills.

  • Source: switch SNMP / gNMI / OpenConfig telemetry
  • What good looks like: zero or near-zero in steady state
  • What bad looks like: steady stream of pauses on one or many ports

Frequent PFC = DCQCN isn't doing its job. Investigate ECN tuning, hash polarization, or hot spots.

3. ECN-marked packets per port​

How often the switch is marking. The signal DCQCN actually reacts to.

  • Source: switch telemetry
  • What good looks like: non-zero but bounded — proves ECN/DCQCN is working
  • What bad looks like: zero (ECN not configured) or saturated (network is overloaded)

4. RDMA NIC errors per pod / per VF​

NIC-side counters: send queue errors, completion queue errors, retransmits, timeouts.

  • Source: ibstat, ethtool -S, vendor telemetry exporters
  • What good looks like: zero or near-zero
  • What bad looks like: non-zero retransmits (sign of drops despite PFC), timeouts (sign of severe issues)

A single retransmit anywhere is a flag.

5. ECMP imbalance / per-link utilization​

Are some links carrying 95% of traffic while others sit at 20%? That's hash polarization.

  • Source: switch per-interface counters
  • What good looks like: even distribution across ECMP members
  • What bad looks like: persistent imbalance, especially on specific 5-tuple flows

The dashboards you should have​

Three dashboards, all should be visible to the on-call engineer at a glance:

Dashboard 1: Fabric health (network engineer view)​

  • Per-port utilization (heatmap or top-N)
  • PFC pauses/sec, by port and direction
  • ECN marks/sec, by port
  • BGP session status (any flapping?)
  • Optical levels (light getting weak?)
  • Buffer occupancy peaks (which queue is filling?)

Dashboard 2: Job health (training team view)​

  • AllReduce time per step (current job, last hour)
  • Network-attributed time (NCCL provides this with debug instrumentation)
  • GPU idle time (proxy for "waiting on network")
  • Per-rank throughput variance (which rank is slowest?)

Dashboard 3: NIC health​

  • Per-NIC retransmit counters
  • Per-NIC completion queue errors
  • Per-VF (in k8s) error counters
  • Driver versions (mismatch is a common bug)

What you'll find in NIC counters​

NIC counters are gold. Modern RDMA NICs expose hundreds of them — these are the ones to actually watch:

ethtool -S enp01s0 | grep -E "(rx_prio|tx_prio|out_of_buffer|out_of_sequence|timeout|cnp)"

Key counters and what they mean:

CounterGoing up means
rx_prio3_pause / tx_prio3_pausePFC pauses received/sent on RoCE priority
out_of_buffer_discardsReceive buffer overflowed — fabric is broken somehow
out_of_sequencePackets arriving out of order — usually adaptive routing or multipath
port_xmit_waitTransmitter is waiting (paused or backpressured)
port_rcv_packets / port_xmit_packetsCounter sanity check
np_cnp_sent / rp_cnp_handledDCQCN signals — actively working

Build a script that polls these every 10 seconds and exports to Prometheus. Set alerts on anomalies.

What about the training framework's view?​

You also need the training-framework-side telemetry. NCCL with NCCL_DEBUG=INFO logs every send/receive timing. Most production training jobs have:

  • Custom NCCL plugin or wrapper that emits per-step timings to a metrics endpoint
  • Per-rank latency histograms (which GPU is slowest? where?)
  • KV-cache stats if inference

This is the training team's responsibility, but you should know how to read it.

Telemetry export pipelines​

The pipeline that gets all this into Prometheus or your TSDB:

Switch  ──gNMI/sFlow──┐
                       ├──→  Telemetry collector (gNMI-collector / sFlow-rt)
NIC counters  ─Prom────┘                       │
(node_exporter / DCGM)                          │
                                                ▼
Training framework  ──Prom──────→ Prometheus  ──→ Grafana
(NCCL plugin)
                                                ▼
                                              Alertmanager  →  PagerDuty

Most large operators have a custom collector for switch telemetry (gNMI is the modern standard), and every switch vendor exposes it:

  • NVIDIA Spectrum-X ships a collector via NVIDIA DOCA.
  • Broadcom Tomahawk white-box switches expose gNMI through the SONiC stack — it's built in, no vendor agent required.
  • On the host side, the source is vendor-specific too: NVIDIA GPUs report via DCGM, AMD GPUs via rocm-smi, and the RDMA NIC counters are vendor-neutral — ethtool -S and the standard RDMA HCA counters (the OFED / rdma-core counter set) read the same whether the NIC is Mellanox, Broadcom, or Intel.

💡 What you should remember​

#ConceptWhy it matters
1📊Five golden signals:AllReduce time, PFC pauses, ECN marks, NIC errors, ECMP balance.
2🖥️Three dashboards:fabric health, job health, NIC health. All visible at a glance.
3🔌NIC counters are goldethtool -S shows the hundreds of useful ones.
4🧠Training framework telemetryis your customer view. Insist on it being plumbed in.
5📡gNMI is the modern switch telemetry protocol.sFlow is the old standard. SNMP is barely sufficient.
6⚠️Set alerts on anomalies, not absoluteswhat matters is sudden changes from baseline.

Next: Common Failure Modes → — the actual failures you'll see, what they look like in the telemetry, and how to triage them.
